ATH Cross Lift® 40 OGA
15 121,85 €
plus bez podatków, transportu
18 146,22 €
Availability:
In stock
SKU
631026
- High-quality and robust hydraulic drive platform scissor lift with minimal maintenance requirements
- Powerful hydraulic unit with load-dependent lowering speed controller
- Suitable installation on-ground with inclusive Kit for surface mounting
- With recesses for turning plates in the front and mechanically lockable sliding plates in the back, free-wheel lift (loading capacity: 4 t, lifting height: 450 mm), including rails for the optional rolling bridge jack, pluggable platforms-connections beams, incl. metal protections covers and switch for the optional 24V LED Lighting.
- Pneumatic unlocking of the safety locks, CE-Stop and acoustic signal through lowering
- Emergency lowering device for lowering in case of power failure, monitoring of safety synchronization by light barrier.
- Ideally suited for inspection, wheel alignment, repairing jobs and testing stations for driver assistance systems
| Kolor | Anthrazit / czerń |
|---|---|
| Udźwig | 4.000 kg |
| Wysokość podnoszenia | 2.160 mm |
| Wysokość najazdu | 295 mm |
| Długość platform | 4.230 mm |
| Szerokość platform | 600 mm |
| Moc napędowa | 3,5 kW |
| Podnoszenie/obniżanie | ca. 70 s |
| Napięcie pracy | 3x 400V / C16A |
| Fundament | min. C20/25 5.500 x 3.000 x 200 mm |
